Plyco’s Series 20 walk doors are designed to be energy efficient, easy to install, and dependable enough to withstand the test of time. Unlike other metal walk doors, the Series 20 makes installation easier, and includes a universal swing feature that allows for up to 8 different configuration options. Contractors can customize their walk doors for a right or left hand in-swing/outswing, choose the key side placement, set the swing-radius, and more!
Material Steel
Application Postframe
Light Commercial
Agricultural Utility
Confinement Out Buildings
Type Pre-Hung
FEATURES
Full rolled edge 24 gauge steel panel, 1 ¾ " thick
Universal swing feature
Four different style of thresholds available: Inswing, Universal, ADA and Outswing
Fully reversible in the 3 ½" thick jamb
16 gauge jamb and panel are galvanized steel
Quality double contact weather stripping on jamb allows for greater leak protection.
Bulb and 3-fin top and bottom weather seals contact header and threshold to greatly reduce water infiltration
Jamb is tooled for hinge and strike mortise, and all jamb mounting holes are counter sunk to allow smooth surface installation
Composite lock block and deadbolt prep are standard
Lock strike plate is adjustable
Passes all ISDI ANSI code tests
OPTIONS
Panic Hardware
Door Closers
Extra heavy duty locksets
Security deadlocks
Passage locksets
Special blocking
Master keyed locksets
Barn door latch
Handicap threshold
Header-Stop for additional weather sealing
3068-4068-6068-8068 Available in 4 colors: Bronze, Hickory Moss, Polar White and Chocolate Brown
3068 available with cross buck and six panel embossing
RESOURCES
Swing Chart
Overall Dimensions
a) For correct out to out dimensions see Data Sheet DO-1 3/0 x 6/8 = 39 ? " x 81 ? "
b) For Rough Opening dimensions, use dimensions (above -a) and add ½ ” to width and ? ” to height
Example: R.O. 3/0 x 6/8 = 39 ? ” + ½” Width x 81 ? ” + ? ” Height = 40 ? ” x 81 ¾ ” Rough Opening
Hinges
(3) 4” X 4” Stainless Steel NRP hinges are standard, Ball-Bearing stainless steel on 4/0 sizes
DOOR PANEL
Thickness
Skin
Smooth 24 gauge galvanized steel painted finish 3068 available in 6-panel or X-Buck styles
Edges
Rolled edge in aluminum core rails
Blocking
HDPE lock reinforcing structure, optional steel closer blocking, Special lock blocking is available
Insulation
Embossing
Colors
Lock Face Prep
Dead Bolt
Optional face bore and edge prep for deadbolt, dbl. notch latchguard available as an option
DOOR FRAME
Type
PREHUNG 16 gauge galvanized steel - Flush plain doors are universal swing with dbl. contact weatherstrip
Material
Features
Aluminum, painted, universal, ADA threshhold is available, Dedicated swing option is available
Frame Depths
3 ½ ” only. Reveal is 1 ? ”
Anchors
Standard frame screws, optional masonry wall clips
Hinge Preps
Face mounted with concealed edges
